雙向差分壓力：

-5 .. 5 mbar up to -1000 .. 1000 mbar

差分壓力/表壓：

0 .. 5 mbar up to 0 .. 2000 mbar

絕對壓力：

0 .. 1000 mbar up to 0 .. 2000 mbar

主要參數

FEATURES
? Calibrated and temperature compensated pressure sensor with two-wire 4 .. 20 mA current loop output
? Differential / gage, bidirectional differential, absolute and barometric versions
? Wide variety of pressure ranges: 5 mbar up to 2 bar
? Piezoresistive sensing element
? High precision digital signal conditioning
? High accuracy at room temperature
? Low overall error within a temperature range of -25 .. +85°C
? Supply voltage range: 8 .. 36 V
? Current limitation
? Protected against reverse polarity
? Compact and robust package
? Dust- and water-tight (IP67)
? M5 circular sensor connector
? Ready to use, simple and quick installation
? RoHS and REACH compliant

GENERAL DEscriptION
AMS 4712 is a series of miniaturized pressure transmitters suitable for industrial applications and high precision measurements. All AMS 4712 can be powered within a supply voltage range of VS = 8 .. 36 V and provide an industrial two-wire 4 .. 20 mA current loop output. They are calibrated and temperature compensated in a wide temperature range of -25 .. +85°C.
AMS 4712 comes in a robust plastic package and is ready to use. Pressure is applied either via two barbed side ports for differential (relative) or bidirectional differential pressure transmitter types or via a single port for absolute or barometric types. The two-wire current loop output is established using an M5 circular sensor connector. AMS 4712’s package is dust- and water-tight conforming to IP67.
The pressure transmitters in the AMS 4712 series are available for various applications and pressure ranges: Differential (relative) devices in pressure ranges from 0 .. 5 mbar up to 0 .. 2 bar, absolute pressure variants for 0 .. 1 bar and 0 .. 2 bar as well as a barometric type for 0.7 .. 1.2 bar. Bidirectional differential devices are available from -5 .. +5 mbar up to -1 .. +1 bar for measurement of positive and negative pressure differences. Other pressure ranges are available on request.

TYPICAL APPLICATIONS
? Static pressure sensing
? Dynamic pressure sensing
? Barometric pressure sensing
? Vacuum measurement
? Level measurement
? Gas flow measurement
? Heating, Ventilation and Air Conditioning (HVAC)
